This full size CCTV security camera has a high resolution Sony™ CCD video sensor and is low light sensitive. It fits in most protective housings and it accepts industry standard C-mount or CS-mount lenses (lenses sold separately).

The heart of a CCTV camera is the video sensor, and the heart of this camera comes from Sony™. Using an industry standard lens mount (with a C-ring included), the 1/3" Super HAD video sensor works with any industry standard C- or CS-mount lens.

Camera:
960H, Full Size, Indoor, Infrared

Get Prices

Price: Login
Points to Purchase:0
Share this product
Item #: ECL-553HQD
Availability: Discontinued notify me

This full size CCTV security camera has a high resolution Sony™ CCD video sensor and is low light sensitive. It fits in most protective housings and it accepts industry standard C-mount or CS-mount lenses (lenses sold separately).

The heart of a CCTV camera is the video sensor, and the heart of this camera comes from Sony™. Using an industry standard lens mount (with a C-ring included), the 1/3" Super HAD video sensor works with any industry standard C- or CS-mount lens to provide an excellent image. Image quality in low and normal light level is aided by a digital signal processing chipset and user selectable backlight compensation and auto-iris control.

Main Features

  • 1/3" color Sony™ ExView CCD video sensor
  • Digital signal processing
  • Super high resolution: 540-line
  • 0.05 LUX minimum illumination, f1.2v
  • Auto-electronic shutter
  • Dual Power: 12VDC or 24VAC
  • 1/3" color Sony™ ExView CCD video sensor
  • Digital signal processing
  • Super high resolution: 540-line
  • Effective pixels: NTSC: 768 x 494 (379k), PAL: 752 x 582 (437k)
  • 0.05 LUX minimum illumination, f1.2v
  • Auto-electronic shutter
  • Auto white balance, auto gain control
  • Back light compensation (selectable)
  • DC or Video auto-iris support (selectable)
  • Built-in anti-aliasing and IR-cut filter
  • C or CS- mount lens compatible (C-ring provided)
  • Non-polarized power plug
  • Dual Power: 12VDC or 24VAC
